Tapered Roller Bearing

37425/37625 Bearing 37425/625 Cup and Cone Set 37425/37625 Tapered Bearing

Dimensions: 107.950*158.750*23.020mm
Mass: 1.35 kg
Mass: 1.35 kg
Cup: 37625
Description:
INQUIRY EMAIL

37425-37625 Bearing Data Sheet:

37425-37625 bearing is single row taper roller bearing, cup and cone set.
For this bearing,
Series: 37000
Cone: 37425
Cup: 37625
Mass: 1.35 kg/set
Material: Chrome Steel, 51200
Dimensions: 107.950*158.750*23.020mm
Drawing: Refer to TIMKEN 37425 – 37625 Bearing
Structure: Cup and Cone Set, Taper Roller Bearing, Imperial
Interchange: 37425-37625, 37425 – 37625, 37425/625, 37425/37625 and so on

Other Imperial Taper Roller Bearing Models:

Bearing Model	Dimensions (d×D×T) mm	Mass (KG)
LL521849C/LL521810	107.950×142.083×15.875	0.620
L521949/L521910	107.950×146.050×21.433	0.990
L521949/L521914	107.950×152.400×21.433	1.180
37425/37625	107.950×158.750×23.020	1.350
LM522546/LM522510	107.950×159.987×34.925	2.340
48190/48120	107.950×161.925×34.925	2.350
56425/56650	107.950×165.100×36.512	2.600
56426/56650	107.950×165.100×36.512	2.540
56425/56662	107.950×168.275×36.512	2.780
67425/67675	107.950×171.450×34.000	2.510
71425/71750	107.950×190.500×47.625	5.570
936/932	107.950×212.725×66.675	10.380
HH224340/HH224310	107.950×212.725×66.675	10.440
37431/37625	109.538×158.750×23.020	1.310
37431A/37625	109.538×158.750×23.020	1.300
