Angular Contact Ball Bearing

  • 30TAC62B 30TAC62BSUC10PN7B
  • 30TAC62B 30TAC62BSUC10PN7B
30TAC62B 30TAC62BSUC10PN7B30TAC62B 30TAC62BSUC10PN7B

30TAC62B 30TAC62BSUC10PN7B

  • SIZE:30*62*15MM
  • Weight : 0.212KG
  • Grade:P4
  • Interchange: 30TAC62CSUHPN7C, 30TAC62C,BS3572
  • Description: NSK ball screw angular contact ball bearing 30TAC62B 30TAC62BSUC10PN7B
  • INQUIRY   EMAIL

30TAC62CSUHPN7C Bearing Spefication:

C: 60° Contact Angle.
SUH: Single Universal Bearing, Heavy Preload.
PN7C: NSK Standard Accuracy Class 7C (Equivalent To Axial Runout Class 2).
Category: Angular Contact Ball Bearings, Single Direction
Inner (d) MM: 30
Outer (D) MM: 62
Width (B) MM: 15
Mass: 0.212kg for 30TAC62CSUHPN7C Bearing
Cage Type P: Plastic Molded Cage
Precision: P2 Precision (Higher than P4)
Manufacture: NSK

Angular contact ball screw bearing models :

Dimensions FAG Code China Code NSK Code R s Mass Load rating Max.axial Attainable Preload
(mm) (kg) (kN) load speed
Cr Grease Fv
d D B min Cr Cor KN min-1 Nmm
12 32 10 7602012TVP 760201 0.6 0.042 12 13 5 8000 1.4
15 35 11 7602015TVP 760202 0.6 0.052 13 15 6 6700 1.3
47 15 BS1547 BSB015047 15TAC47B 0.6 0.058 15 17 7 7500 2.1
17 40 12 7602017TVP 760203 0.6 0.074 17 20 9 6000 1.7
47 15 BS1747 BSB017045 17TAC47B 1 0.114 22 29 15 8000 2.4
20 47 14 7602020TVP 760204 1 0.139 20 26 11 5000 2.3
47 15 BS2047 BSB020047 20TAC47B 1 0.135 22 29 15 8000 2.4
52 15 7603020TVP 760304 1.1 0.17 25 32 14 4500 2.9
25 52 15 7602025TVP 760205 1 0.147 22 31 13 4500 2.5
62 15 BS2562 BSB025062 25TAC62B 1 0.252 29 44 20 5600 3.2
62 17 7603025TVP 760305 1.1 0.275 29 42 18 3800 3.3
30 62 15 BS3062 BSB030062 30TAC62B 1 0.224 29 44 20 5600 3.2
62 16 7602030TVP 760206 1 0.232 26 39 17 3800 2.9
72 19 7603030TVP 760306 1.1 0.409 35 55 24 3200 4.3
35 72 15 BS3572 BSB035072 35TAC72B 1 0.31 31 52 22 4800 3.4
72 17 7602035TVP 760207 1.1 0.339 30 50 21 3200 3.3
80 21 7603035TVP 760307 1.5 0.546 37 61 27 3000 4.8
40 72 15 BS4072 BSB040072 40TAC72B 1 0.275 32 53 22 4800 3.5
80 18 7602040TVP 760208 1.1 0.418 38 64 28 2800 4.3
90 20 BS4090 BSB040090 40TAC90B 1 0.674 59 98 41 4000 6.5
90 23 7603040TVP 760308 1.5 0.751 50 83 36 2600 5.6
45 75 15 BS4575 BSB045075 45TAC75B 1 0.27 33 58 23 4300 3.6
85 19 7602045TVP 760209 1.1 0.488 38 68 28 2600 4.5
100 20 BS45100 BSB045100 45TAC100B 1 0.842 62 109 43 3600 6.8
100 25 7603045TVP 760309 1.5 0.992 59 104 45 2200 7
50 90 20 7602050TVP 760210 1.1 0.557 39 75 32 2400 4.9
100 20 BS50100 BSB050100 50TAC100B 1 0.778 63 121 44 3600 6.9
110 27 7603050TVP 760310 2 1.29 70 127 53 2000 7.6
55 90 15 BS5590 BSB055090 55TAC90B 1 0.537 59 108 41 3200 6.5
100 20 BS55100 BSB055100 55TAC100B 1 0.714 63 114 44 3400 6.9
100 21 7602055TVP 760211 1.5 0.74 41 82 34 2200 4.6
120 20 BS55120 BSB055120 55TAC120B 1 1.23 67 121 47 3000 7.4
120 29 7603055TVP 760311 2 1.67 80 146 63 1900 8.8
60 110 22 7602060TVP 760212 1.5 0.94 56 112 48 2000 6.5
120 20 BS60120 BSB060120 60TAC120B 1 1.16 67 126 47 3000 7.4
