Angular Contact Ball Bearing

25TAC62CSUHPN7C Bearing 25TAC62C Ball Screw Bearing 25x62x15

ID: 25mm
OD: 62mm
Width: 15mm
Precision: P4
Description: 25TAC62C Ball Screw Bearing 25x62x15
INQUIRY EMAIL

25TAC62CSUHPN7C Bearing Specification:

25TAC62CSUHPN7C bearing is high precision ball screw bearing for machine tool spindles.
For this bearing

Cross Reference:	25TAC62CSUHPN7C, 25TAC62C SUHPN7C, 25TAC62C
Mass:	0.252kg
Size:	256215mm
C:	60 degree contact angle
SUH:	Single Universal Bearing, Heavy Preload
BPN7C:	NSK Standard Accuracy Class 7C (Equivalent To Axial Runout Class 2).
Cage Type P:	Plastic Molded Cage
Manufacture:	NSK
Category:	Angular Contact Ball Bearings, Single Direction
Packing:	Standard Export Packing

Ball Screw Bearing Size Chart:

Our Code	FAG	SKF	NSK	NTN
BS1547TN			15TAC 47B
BS1747TN			17TAC 47B	BST17X 47-1B
BS2047TN	BSB020047T	BSD2047	20TAC 47B	BST20X 47-1B
BS2562TN	BSB025062T	BSD2562	25TAC 62B	BST25X 62-1B
BS3062TN	BSB030062T	BSD3062	30TAC 62B	BST30X 62-1B
BS3572TN	BSB035072T	BSD3572	35TAC 72B	BST35X 72-1B
BS4072TN	BSB040072T	BSD4072	40TAC 72B	BST40X 72-1B
BS4090TN	BSB040090T	BSD4090	40TAC 90B	BST40X 90-1B
BS4575TN	BSB045075T	BSD4575	45TAC 75B	BST45X 75-1B
BS45100TN		BSD45100	45TAC 100B	BST45X 100-1B
BS50100TN	BSB050100T		50TAC 100B	BST50X 100-1B
