Angular Contact Ball Bearing

40TAC72B Precision Bearing 40TAC72BSUC10PN7B Angular Contact Bearing 40x72x15

ID:40
OD:72
Width: 15
Precision: P4
Description: 40TAC72BSUC10PN7B Angular Contact Bearing 40x72x15
INQUIRY EMAIL

40TAC72B Precision Bearing Specification:

40TAC72B precision bearing is single direction angular contact thrust ball bearing.
For this bearing,
Dimensions: 40x72x15mm
Weight：0.28kg/piece
Precision: P4/= ABEC7
Material: Gcr15 chrome steel
Lubrication Speed (Oil): 4800 RPM
Lubrication Speed (Grease): 3600 RPM
B: High capacity and higher speed (replaces “A” type)
Category: Ball screw support bearing, angular contact thrust ball bearing
Interchange Numbers: 40TAC72B, 45TAC 72B, 40TAC72BSUC10PN7B, BSB4072-SU, BSB040072T, BSD4072CGA, etc.

Precision Ball Screw Support Bearings Chart:

Our Code	FAG	SKF	NSK	NTN
BS1547TN			15TAC 47B
BS1747TN			17TAC 47B	BST17X 47-1B
BS2047TN	BSB020047T	BSD2047	20TAC 47B	BST20X 47-1B
BS2562TN	BSB025062T	BSD2562	25TAC 62B	BST25X 62-1B
BS3062TN	BSB030062T	BSD3062	30TAC 62B	BST30X 62-1B
BS3572TN	BSB035072T	BSD3572	35TAC 72B	BST35X 72-1B
BS4072TN	BSB040072T	BSD4072	40TAC 72B	BST40X 72-1B
BS4090TN	BSB040090T	BSD4090	40TAC 90B	BST40X 90-1B
BS4575TN	BSB045075T	BSD4575	45TAC 75B	BST45X 75-1B
BS45100TN		BSD45100	45TAC 100B	BST45X 100-1B
BS50100TN	BSB050100T		50TAC 100B	BST50X 100-1B
BS5590TN	BSB055090T
BS55100TN	BSB055100T		55TAC 100B	BST55X 100-1B
BS55120TN	BSB055120T		55TAC 120B	BST55X 120-1B
BS60120TN	BSB060120T		60TAC 120B	BST60X 120-1B
