Angular Contact Ball Bearing

35TAC72B Bearing 35TAC72BSUC10PN7B Spindle Bearings 357215

ID:35
OD:75
Width: 15
Precision: P4
Description: 35TAC72BSUC10PN7B Spindle Bearings
INQUIRY EMAIL

35TAC72B Bearing Data Sheet:

35TAC72B bearing is high precision bearing for machine tool spindles.
For this bearing,
Dimensions: 35*72*15mm
Mass: 0.31kg/pc
Material: 51200 steel
Cage: Standard steel cage
B: High capacity & higher speed
SU: Single universal
C10: Metric series
PN7B: Bore And O.D. tolerance is tighter
Structure: Angular contact thrust ball bearings, ball screw support bearing
Cross Reference: 35TAC72B, 35TAC 72B, BST35X 72-1B, BSD3572, BSB035072T, 35TAC72BSUC10PN7B

Ball Screw Bearing Size Chart:

Our Code	FAG	SKF	NSK	NTN
BS1547TN			15TAC 47B
BS1747TN			17TAC 47B	BST17X 47-1B
BS2047TN	BSB020047T	BSD2047	20TAC 47B	BST20X 47-1B
BS2562TN	BSB025062T	BSD2562	25TAC 62B	BST25X 62-1B
BS3062TN	BSB030062T	BSD3062	30TAC 62B	BST30X 62-1B
BS3572TN	BSB035072T	BSD3572	35TAC 72B	BST35X 72-1B
BS4072TN	BSB040072T	BSD4072	40TAC 72B	BST40X 72-1B
BS4090TN	BSB040090T	BSD4090	40TAC 90B	BST40X 90-1B
BS4575TN	BSB045075T	BSD4575	45TAC 75B	BST45X 75-1B
BS45100TN		BSD45100	45TAC 100B	BST45X 100-1B
BS50100TN	BSB050100T		50TAC 100B	BST50X 100-1B
