Angular Contact Ball Bearing

50TAC 100B Bearing BSD50100G High Precision Ball Bearing 5010020

ID:50
OD:100
Width:20
Precision: P4
Description: 50TAC100B Bearing BSD50100G High Precision Ball Bearing
INQUIRY EMAIL

50TAC 100B Bearing Introduction:

50TAC 100B bearing is for supporting ball screws.
Inner Diameter: 50mm
Outer Diameter: 100mm
Height: 20mm
Weight: 0.778kg/piece
Material: chrome steel
Cage: molded polyamide
Precision: P4/ ABEC7 level
Limit Speed (Oil): 3400 RPM
Limit Speed (Grease): 2600 RPM
Also Known As: 50TAC100B, 50TAC 100B, 50 TAC 100B, BSD50100G, BSB50100-SU, 50TAC100BSUC10PN7B and so on

50TAC100B Bearing Features:

1. 50 TAC 100B belong to precision ball bearing, and precision is P4 level, equals to ABEC7.
2. They are usually used in combinations of more than 2 bearings and with a preload.
3. Bearing contact angle is 60 degrees.
4. A tolerance of h5 is recommended for shafts and H6 for housing bores.

Precision Ball Screw Supporting Bearing Chart:

Our Code	FAG	SKF	NSK	NTN
BS1547TN			15TAC 47B
BS1747TN			17TAC 47B	BST17X 47-1B
BS2047TN	BSB020047T	BSD2047	20TAC 47B	BST20X 47-1B
BS2562TN	BSB025062T	BSD2562	25TAC 62B	BST25X 62-1B
BS3062TN	BSB030062T	BSD3062	30TAC 62B	BST30X 62-1B
BS3572TN	BSB035072T	BSD3572	35TAC 72B	BST35X 72-1B
BS4072TN	BSB040072T	BSD4072	40TAC 72B	BST40X 72-1B
BS4090TN	BSB040090T	BSD4090	40TAC 90B	BST40X 90-1B
BS4575TN	BSB045075T	BSD4575	45TAC 75B	BST45X 75-1B
BS45100TN		BSD45100	45TAC 100B	BST45X 100-1B
BS50100TN	BSB050100T		50TAC 100B	BST50X 100-1B
BS5590TN	BSB055090T
BS55100TN	BSB055100T		55TAC 100B	BST55X 100-1B
BS55120TN	BSB055120T		55TAC 120B	BST55X 120-1B
