Inquiry:
Angular Contact Ball Bearing
45TAC100B Bearing 45TAC100BSUC10P Angular Contact Bearing 40x100x20
- ID:45
- OD:100
- Width:20
- Precision: P4
- Description: 45TAC100BSUC10P Angular Contact Bearing 40x100x20
45TAC100B Bearing Specification:
45TAC100B bearing is single row angular contact ball bearing.
For this bearing model,
Size: 40x100x20mm
Weight: 0.842kg/piece
Material: chrome steel
Cage: molded polyamide
Precision: P4/ ABEC7 level
Limit Speed (Oil): 3600 RPM
Limit Speed (Grease): 2600 RPM
B: high capacity and higher speed
SU: single universal
C10: metric series
Interchange Numbers: 45TAC100B, 45 TAC 100B, 45TAC 100B, 45TAC100BSUC10P, BS45100, etc
Ball Srew Support Bearings Model List:
| Bearing Dimensions | NSK Model Number | FAG Model Number |
| 15*47*15 | 15TAC47B | BS1527 |
| 17*47*15 | 17TAC47B | BS1747 |
| 20*47*15 | 20TAC47B | BS2047 |
| 25*62*15 | 25TAC62B | BS2562 |
| 30*62*15 | 30TAC62B | BS3062 |
| 30*72*15 | 30TAC72B | BS3072 |
| 35*72*15 | 35TAC72B | BS3572 |
| 40*72*15 | 40TAC72B | BS4072 |
| 40*90*20 | 40TAC90B | BS4090 |
| 45*75*15 | 45TAC75B | BS4575 |
| 45*100*20 | 45TAC100B | BS45100 |
| 50*100*20 | 50TAC100B | BS50100 |
| 55*90*15 | 55TAC90B | BS5590 |
| 55*100*20 | 55TAC100B | BS55100 |
| 55*120*20 | 55TAC120B | BS55120 |
| 60*120*20 | 60TAC120B | BS60120 |
